Electric Vehicle Battery Charger/Discharger
Electric Vehicle Battery Charger/Discharger
This Electric Vehicle Battery Charger/Discharger is a portable charging and discharging device specifically engineered for the maintenance of battery modules or entire battery packs. By incorporating a design of feeding back to power grid, it achieves a small footprint while delivering high power, ensuring ease of portability and ideal for service personnel on long distance travel. It efficiently facilitates voltage matching for automotive battery modules and energy storage plug-in boxes, as well as routine maintenance and capacity calibration.
Send Inquiry
Product Description
Application scenarios
Advantages & features
1. Supporting multiple methods such as built-in collection and CAN communication to obtain single cell voltage, ensuring safe charging and discharging processes.
2. Supporting wide voltage range battery charging and discharging, suitable for battery modules or pack maintenance of different voltages.
3. Adopting advanced bidirectional power supply technology, the power discharged can be fed back to power grid to save energy.
4. Simple interface and easy to operate.
Parameters
|
Model |
ACNE-NM20-5060 |
|
Power supply |
110V~253V AC |
|
Frequency range |
50/60Hz±5Hz |
|
Maximum output power |
6kW (110V input, power halved) |
|
Output voltage range |
10~450V |
|
Output current range |
±60A Max |
|
Output voltage accuracy |
±0.1%FS |
|
Output current accuracy |
±0.5%FS |
|
Charging and discharging mode |
CC-CV |
|
Cooling method |
Forced air cooling |
|
Dimension (L*W*H) |
250*530*290mm |
|
Weight |
17kg |
|
Cell voltage acquisition accuracy |
≤5mV |
|
Temperature acquisition accuracy |
±1℃ |
|
Power factor |
0.99 |
|
Current harmonics |
＜5% |
